Case Study – Architectural BIM for an Industrial Project in CT

Architectural-BIM-for-an-Industrial-Project-in-CT

Provided Architectural BIM for Industrial Project in Ellington, CT

United-BIM has provided 2D drafting & 3D BIM models for architectural trades (elements and components) for an industrial project in Ellington, CT

  • Project Name : Industrial Project, Ellington, CT
  • Services Provided : Architectural Drafting | 3D Architectural Modeling
  • Client : An Integrated Architecture, Engineering and Construction Firm
  • LOD : 300
  • Tools : AutoCAD, Revit
UNITED-BIM GOALS
  • 2D architectural PDF
  • 2D CAD Drawings
  • 3D Architectural Revit Model
  • LOD 300 Revit Model
Project Brief
  • The client wanted us to develop 2D CAD Drawings and 3D BIM Models for this new construction of an Industrial project based in Ellington, CT. The project scope was to produce accurate architectural drafting and modeling at LOD 350. We used Revit and AutoCAD to develop 2D CAD drawings and 3D BIM models at LOD 350 for all the Architectural elements and components.

The client wanted us to develop 2D CAD Drawings and 3D BIM Models for this new construction of an Industrial project based in Ellington, CT. The project scope was to produce accurate architectural drafting and modeling at LOD 350. We used Revit and AutoCAD to develop 2D CAD drawings and 3D BIM models at LOD 350 for all the Architectural elements and components.

Accutime-Systems-Architectural-Modeling-Services-by-United-BIM
Accutime-Systems-Architectural-Modeling-Services-by-United-BIM_
Section-View-Accutime-Systems-Architectural-Modeling-Services-by-United-BIM

Project Skills & Expertise

The BIM authoring software used for the execution of this project was Revit from Autodesk’s 2018 AEC collection package. Dedicated BIM modelers from our architectural modeling team worked in sync to develop accurate BIM model and 2D CAD drawings.
